High Flow Filter Cartridge 5 Micron

High Flow Filter Cartridge 5 Micron adalah filter lipat lipat yang berdiameter besar berbahan polypropylene dengan model salah satu ujung terbuka dan berkapasitas 20 hingga 70 kali lipat lebih besar dari kapasitas filter berukuran standard Respon cepat +62 813 8506 6789

Description

High Flow Filter Cartridge 5 Micron

Kami adalah importir distributor agen dan supplier High Flow Filter Cartridge 5 Micron terlengkap menyediakan berbagai kebutuhan spare part water treatment  untuk keperluan industri dengan kualitas dan harga terbaik.



Description High Flow Pleated Filter Cartridge

PFI Watermaker HFCP Series is made of diameter 6 ” (152.4mm) , single open end, without or and with inner core, inside to outside flow direction.

The HFCP series pleated high flow filter is constructed with 6 inch (152 mm) large diameter which offers super high flow rate, it can greatly save water treatment plant footprint and reduce filter change-out cost.

Inside-out flow operation keeps all the contaminants inside the filter thus making replacement process more convenient.

Available filter media includes polypropylene and microfiber glass with pore size from 0.5μm to 100μm. PFI HFCP series provides a more cost-effective solution to replace PP Watermaker high flow filters.



Product Specifications Filter High Flow

Media/Support/Cage: Polypropylene

End caps: Polypropylene

O-rings : EPDM, Silicone, Buna-N, Viton

Micron ratings : 1 – 100 μm

Dimensions Cartridge High Flow

Nominal lengths : 20″, 40″, 60″

Outside diameter : 6.0″ (15.2 cm)

Surface area :

  • 24 ft 2. (2.2 m2) per 20″ elementt
  • 49 ft 2. (4.6 m2) per 40″ element
  • 73 ft 2. (6.8 m2) per 60″ element

Operating Parameters

Maximum operating temperature : 77°F @ 50 psid (25°C @ 3.4 bar)

Recommended changeout differential pressure: 35 psid (2.4 bar)

Maximum flow rates :

  • 60″ element up to 500 GPM (1892 lpm)
  • 40″ element up to 350 GPM (1325 lpm)
  • 20″ element up to 175 GPM (662 lpm)



Features of High Flow Filter Cartridges

  • High contaminant holding capacity for long life
  • All materials of construction are FDA listed
  • Fewer cartridges for fewer change-outs, thus less labor and disposal cost
  • Thermally bonded ensure structure integrity and no additives
  • Heavy wall core offers superior strength
  • Integrated handle makes change out fast, easy and safe
  • Inside-to-outside flow traps particulate within filter
  • External netting for additional support
  • Compatible with most brand standard high flow filter housings.

PFI HFCP high flow filter housing Pall Replacement provides better protection for RO membrane than melt blown and string wound sediment filter cartridges.

Untuk Informasi penawaran dan stock High Flow Filter Cartridge 5 Micron silahkan hubungi kami



Alamat kontak

PT PROFILTER INDONESIA

Ruko Blok G/54 – Gudang A/01

Jl.Canadian Broadway

Kawasan Pergudangan Commpark

Kotawisata – Cibubur

Kantor : +6221 84937805 , 84937329

Mobile : 081385066789

Email : sales@profilterindonesia.co.id
